pneumatic asphalt mixture rutting sample forming machine HYCX-3
pneumatic asphalt mixture rutting sample forming machine HYCX-3
pneumatic asphalt mixture rutting sample forming machine HYCX-3.jpg
1.features
l Adopting pneumatic method to produce vertical pressure, very accurate.
l The pressure keeps constant even at the moment the wheel mill runs reversely.
l The pneumatic model is easier to maintain and clean when compare to hydraulic model.
l Adopting LCD touch screen display.
l Built-in surge-tank, pressure constant, low noise
l The pressure can be corrected after adjust the line load.
2.specifications
No. | Item | Spec |
1 | Test sample size | 300x300x50mm(standard) 300x300x100mm(optional) |
2 | Roller diameter | 1000mm |
3 | Roller width | 300mm |
4 | Speed of test sample car | 6 round trips/minute |
5 | Roller pressure | 0-20KN adjustable(pre-set at 9KN ) |
6 | Pressure accuracy | 0.5% |
7 | Roller temperature | 50-200℃ |
8 | Dimension | 1250x650x1930mm |
9 | Weight | 372kg |
10 | Voltage | 380V±10% |
11 | Power | 3kW |
